Titanium Alloy Grade 12 is lightly alloyed near-alpha alloy offering improved strength at elevated temperatures and optimum ASME Code design allowables. The material is readily weldable, and has superior crevice corrosion resistance. This material is very corrosion resistant in highly oxidizing and mildly reducing environments.
Standard Specification: ASTM B338 ASTM B861, ASTM B862 GB/T3625
Standard |
Werkstoff No. |
UNS |
Titanium Alloy Grade 12 Ti-0.3Mo-0.8Ni |
3.7105 |
R53400 |
Technical Data Sheet
Chemical Composition |
|||||||||
Weight % |
Ti |
Mo |
Ni |
C |
Fe |
N |
O |
H |
|
Titanium Alloy Grade 12 Ti-0.3Mo-0.8Ni |
Balance |
0.2~0.4 |
0.6~0.9 |
0.08 |
0.3 |
0.03 |
0.25 |
0.015 |
Typical Mechanical Properties (Tensile Requirements)
Material |
Tensile Strength, min |
Yield Strength (0.2% Offset) min or range |
Elongation in 4D,min% |
Reduction of Area Min % |
||
ksi |
MPa |
ksi |
MPa |
|||
Titanium Alloy Grade 12 Ti-0.3Mo-0.8Ni |
70 |
483 |
50 |
345 |
18 |
25 |
GOOLEE titanium seamlesstubes and pipes are widely used in condensers, heat exchangers, aerospace fuel pipes, bicycles, golf carts and motorcycles, etc. Products
GOOLEE titaniumwelded tubes and pipes are widely used in condensers, heat exchangers, 1.Outer Diameter10mm~114mm×Wall Thickness0.5mm~2mm×Length25000mm; 2.Material: Titanium Grade1, 2, 12 Standar
Titanium Alloy Grade5 Ti-6Al-4V Ti-6Al-4V alloy is the most widely used titanium alloy of the alpha-plus-beta class,and is also the most common of all titanium alloys. The alloy is castable and is&nb
Listed in the following table are some of the common sizes produced for major aircraft companies. Sizes other than those shown can be produced depending on the quantity required. SEAMLESS T
