Titanium Alloy Grade 3 is “unalloyed” titanium offering improved strength,
moderate ductility, and ASME Code design allow ables. The material is readily
weld able. This material is very corrosion resistant in highly oxidizing and
mildly reducing environments.
Standard: ASMESB338; ASTM B861; ASTM B862;AMS4942;AMS4945;AMS4944;AMS4943; GB/T3625;
Standard |
Werkstoff No. |
UNS |
Commercial Pure Titanium Grade3 |
3.7055 |
R50550 |
Technical Data Sheet
Chemical Composition |
||||||
Weight % |
Ti |
C |
Fe |
N |
O |
H |
Commercial Pure Titanium Grade3 |
Balance |
0.08 |
0.3 |
0.05 |
0.35 |
0.015 |
Typical Mechanical Properties (Tensile Requirements)
Material |
Tensile Strength, min |
Yield Strength (0.2% Offset) min or range |
Elongation in 4D,min% |
Reduction of Area Min % |
||
ksi |
MPa |
ksi |
MPa |
|||
Commercial Pure Titanium Grade3 |
64 |
450 |
55 |
380 |
18 |
30 |
