Titanium Ti5Al2.5Sn (Grade 6) is a high strength alloy which is most commonly used in airframe and jet engine applications. Titanium Ti5Al2.5Sn (Grade 6) has good weldability, stability and strength at elevated temperatures.
Standard Specification:
AMS 4909 Sheet, Strip, Plate (EL1 grade)
AMS 4910 Sheet, Strip, Plate;
AMS-T- 9046 A-1 Sheet, Strip, Plate;
AMS-T-9046 A-2 (EL1) Sheet, Strip, Plate;
MIL-T-9046J A-1 Sheet, Strip, Plate;
MIL-T-9046H Type II Comp A Sheet, Strip, Plate;
MIL-T-9046H Type II Comp B Sheet, Strip, Plate;
Standard |
Werkstoff No. |
UNS |
Titanium Alloy Grade 6 / Ti-5Al-2.5Sn |
3.7114 |
R54520 |
Technical Data Sheet
Chemical Composition |
|||||||||
Weight % |
Ti |
Al |
Sn |
C |
Fe |
N |
O |
H |
Other |
Titanium Alloy Grade 6 / Ti-5Al-2.5Sn |
Balance |
4.0~6.0 |
2.0~3.0 |
0.1 |
0.05 |
0.05 |
0.2 |
0.020 |
0.4 Total Max. |
Typical Mechanical Properties (Tensile Requirements)
Material |
Tensile Strength, min |
Yield Strength (0.2% Offset) min or range |
Elongation in 4D,min% |
||
ksi |
MPa |
ksi |
MPa |
||
Titanium Alloy Grade 6 / Ti-5Al-2.5Sn |
120 |
830 |
115 |
795 |
10 |
