Titanium Alloy Grade 2 is “unalloyed” titanium offering an excellent balance
of strength and ductility. The material has good toughness and is readily weldable. This material is very corrosion resistant in highly oxidizing and mildly reducing environments.
Standard Specification: ASTM B265 , ASME SB265, ASTM F67, AMS-T-9046B CP4 AMS 4940 MIL-T-9046J CP4
Standard |
Werkstoff No. |
UNS |
Commercial Pure Titanium Grade2 |
3.7035 | R50400 |
Technical Data Sheet
Chemical Composition |
||||||
Weight % |
Ti |
C |
Fe |
N |
O |
H |
Commercial Pure Titanium Grade2 |
Balance | 0.08 | 0.3 | 0.03 | 0.25 | 0.015 |
Typical Mechanical Properties (Tensile Requirements)
Material |
Tensile Strength, min |
Yield Strength (0.2% Offset) min or range |
Elongation in 4D,min% |
Reduction of Area
Min % |
||
ksi | MPa | ksi | MPa | |||
Commercial Pure Titanium Grade2 | 50 | 345 | 40 | 275 | 20 | 30 |
Titanium 8-1-1 (8Al-1Mo-1V) is a near alpha alloy offering good weldability and with superior creep resistance at operating temperature up to 450°C. Alloy 8-1-1 has a relatively high tensile modulus t
Titanium Alloy Grade 3 is “unalloyed” titanium offering improved strength,moderate ductility, and ASME Code design allowable. The material is readily weldable. This material is very corrosion res
Titanium Ti5Al2.5Sn (Grade 6) is a high strength alloy which is most commonly used in airframe and jet engine applications. Titanium Ti5Al2.5Sn (Grade 6) has good weldability, stability and strength a
