Standard Specification: ASTM B863, ASME SB863, ISO, DIN AWS A5.16 (ERTi-36);
Standard |
Werkstoff No. | UNS |
Titanium Alloy Grade 36 Ti45-Nb |
~ | R58450 |
Technical Data Sheet
Chemical Composition |
||||||||
Weight % | Ti | Nb | C | Fe | N | O | H | |
Titanium Alloy Grade 36 Ti45-Nb |
Balance | 42~47 | 0.04 | 0.03 | 0.03 | 0.16 | 0.0035 |
Typical Mechanical Properties (Tensile Requirements)
Material | Tensile Strength, min | Yield Strength (0.2% Offset) min or range | Elongation in 4D,min% | Reduction of Area
Min % |
||
ksi | MPa | ksi | MPa | |||
Titanium Alloy Grade9 Ti-3Al-2.5V |
65 | 450 | 60~95 | 410~655 | 10 | ~ |
Titanium Alloy Grade9 Ti-3Al-2.5V alloy is an alpha alloy that is strengthened by cold working. The material exhibits good ductility and toughness. It is used in a wide range of tubular prod
Titanium Alloy Grade 2 is “unalloyed” titanium offering an excellent balance of strength and ductility. The material has good toughness and is readily weldable. This material is very corrosi
Titanium Alloy Grade 12 is lightly alloyed near-alpha alloy offering improved strength at elevated temperatures and optimum ASME Code design allowables. The material is readily weldable, and
T Titanium Alloy Grade5 Ti-6Al-4V Ti-6Al-4V alloy is the most widely used titanium alloy of the alpha-plus-beta class,and is also the most common of all titanium alloys. The alloy is castable and
